| Τύπος: | Μονωμένο XLPE καλώδιο τροφοδοσίας | Χαρακτηριστικό: | Χαμηλή τάση |
|---|---|---|---|
| Εικονική οθόνη:: | Ημιαγωγός | Δείγμα: | Ελεύθερος |
| Χρώμα μόνωσης: | κίτρινος, μπλε | Πλεονεκτήματα: | Αντίσταση στην τριβή |
| Κεφαλή: | PVC ή FR-PVC τύπου ST2 έως IEC 60502, μαύρο | Εικόνα: | Ταινία χαλκού |
| εταιρία: | ομάδα shenghua | Μάρκα: | Διάδρομο |
| Επισημαίνω: | XLPE insulated power cable 21/35kV,abrasion-resistant XLPE power cable,IEC-certified XLPE insulated cable |
||
| Attribute | Value |
|---|---|
| Type | XLPE Insulated Power Cable |
| Feature | Low Voltage |
| Conductor Screen | Semi-conductor |
| Sample | Free |
| Insulation Color | Yellow, Blue |
| Advantage | Abrasion Resistance |
| Sheath | PVC or FR-PVC type ST2 to IEC 60502, black |
| Screen | Copper tape |
| Corporation | Shenghua Group |
| Brand | SH Cable |
Shenghua's low-voltage XLPE insulated power cables (21/35(36)kV) combine cutting-edge engineering with extreme abrasion resistance, delivering reliable power transmission for industrial grids, renewable energy farms, and urban infrastructure. Trusted across 60+ countries, our cables ensure safety, efficiency, and compliance with global standards.
| Conductor (mm²) | Max. DC Resistance (Ω/km) | Current Rating (Soil, A) | Approx. Weight (kg/km) | Key Application |
|---|---|---|---|---|
| 4 × 185 | 0.164 | 305 | 3,091 | Industrial plants/substations |
| 4 × 400 | 0.0778 | 445 | 5,840 | High-load renewable energy hubs |
| 4 × 300 | 0.100 | 400 | 4,830 | Metro tunnels & urban grids |
| Nom. Cross-section of conductor | Strands No./Dia. Of Conductor | Insulation Thickness | Sheath Thickness | Approx. O.D. | Approx. Weight | Max. D.C Resistance of Conductor (20 ℃) | Testing Voltage A.C | Current Rating In air (A) | Current Rating In soil(A) |
|---|---|---|---|---|---|---|---|---|---|
| 4 × 4 | 1/2.25 | 0.7 | 1.8 | 13.0 | 155 | 7.41 | 3.5 | 27 | 36 |
